Pololu 47:1 Metal Gearmotor 25Dx52L mm LP 6V with 48 CPR Encoder

Features:

• This gearmotor consists of a low-power, 6 V brushed DC motor combined with a 46.85:1 metal spur gearbox, and it has an integrated 48 CPR quadrature encoder on the motor shaft, which provides 2248.86 counts per revolution of the gearbox’s output shaft
• The gearmotor is cylindrical, with a diameter just under 25 mm, and the D-shaped output shaft is 4 mm in diameter and extends 12.5 mm from the face plate of the gearbox
• Key specs at 6 V: 120 RPM and 250 mA free-run, 65 oz-in (4.7 kg-cm) and 2.4 A stall

Details: This gearmotor consists of a low-power, 6 V brushed DC motor combined with a 46.85:1 metal spur gearbox, and it has an integrated 48 CPR quadrature encoder on the motor shaft, which provides 2248.86 counts per revolution of the gearbox’s output shaft. The gearmotor is cylindrical, with a diameter just under 25 mm, and the D-shaped output shaft is 4 mm in diameter and extends 12.5 mm from the face plate of the gearbox.

UPC: 810012581035

EAN: 0810012581035

Model: 2285

Item Condition: New
